Position Data Calculation
718
FH/FZ5 Processing Item Function Reference Manual
130 Lower limit of calculate angle Set/Get -180.0000 to 180.0000
131 Point 0:X Set/Get Exp. character string
132 Point 0:Y Set/Get Exp. character string
133 Point 0:Angle Set/Get Exp. character string
141 Point 1:X Set/Get Exp. character string
142 Point 1:Y Set/Get Exp. character string
143 Point 1:Angle Set/Get Exp. character string
151 Point 2:X Set/Get Exp. character string
152 Point 2:Y Set/Get Exp. character string
153 Point 2:Angle Set/Get Exp. character string
161 Point 3:X Set/Get Exp. character string
162 Point 3:Y Set/Get Exp. character string
163 Point 3:Angle Set/Get
Exp. character string
No. Data name Set/Get Data range
