Camera CalibrationFH/FZ5 Processing Item Function Reference Manual
825
4
Support Inspection and Measurement
140 Number of sampling specifications Set/Get 0 to 100
141 Operational sampling number Set/Get -1 to 99
142 Sampling unit X Set/Get
-1: OFF
0 to 9999
144 Sampling unit Y Set/Get
-1: OFF
0 to 9999
146 Maximum number of figure data Get only -
147 Sampling mode Set/Get
0: Individual
1: Global
150 Coordinate Set/Get
0: Right-hand type
1: Left-hand type
151 Origin Set/Get
0: Upperleft
1: Lowerleft
2: Center
3: Specify the coordinates
152 Actual width Set/Get 0.0001 to 99999.9999
154 Camera coordinate X Set/Get -99999.9999 to 99999.9999
155 Camera coordinate Y Set/Get -99999.9999 to 99999.9999
156 Post-conversion coordinate X Set/Get -99999.9999 to 99999.9999
157 Post-conversion coordinate Y Set/Get -99999.9999 to 99999.9999
158 Width reference unit Set/Get
-1: OFF
0 to 9999
159 Point reference unit 1 Set/Get
-1: OFF
0 to 9999
160 Point reference unit 2 Set/Get Point 2 reference unit No.
161 Dimensional measurement mode Set/Get
0: Width specification
1: 2-point specification
170
Calibration parameter A (before
co
mp
ensation)
Set/Get -99999.999999 to 99999.999999
171
Calibration parameter B (before
co
mp
ensation)
Set/Get -99999.999999 to 99999.999999
172
Calibration parameter C (before
co
mp
ensation)
Set/Get -99999.999999 to 99999.999999
173
Calibration parameter D (before
co
mp
ensation)
Set/Get -99999.999999 to 99999.999999
174
Calibration parameter E (before
co
mp
ensation)
Set/Get -99999.999999 to 99999.999999
175
Calibration parameter F (before
co
mpensation)
Set/Get -99999.999999 to 99999.999999
176
X magnification ratio (before
co
mpensation)
Get only -
177
Y magnification ratio (before
co
mp
ensation)
Get only -
178 Origin X (before compensation) Get only -
179 Origin Y (before compensation) Get only -
180 X axis angle (before compensation) Get only -
181 Y axis angle (before compensation) Get only
-
No. Data name Set/Get Data range
To Next Page
