Camera Calibration
826
FH/FZ5 Processing Item Function Reference Manual
182 XY angle (before compensation) Get only -
183 Compensation ratio X Set/Get 0.5000 to 1.5000
184 Compensation Y Set/Get 0.5000 to 1.5000
185 Compensation angle X Set/Get -180.0000 to 180.0000
186 Compensation angle Y Set/Get -180.0000 to 180.0000
187 Origin offset X Set/Get -9999.9999 to 9999.9999
188 Origin offset Y Set/Get -9999.9999 to 9999.9999
200 + N × 1
(N = 0 to 99)
Camera coordinate X for Point N
(point specificatio
n)
Set/Get 0.0000 to 99999.9999
300 + N × 1
(N = 0 to 99)
Camera coordinate Y for Point N
(p
oint specification)
Set/Get 0.0000 to 99999.9999
400 + N × 1
(N = 0 to 99)
Actual coordinate X for Point N
(p
oint specification)
Set/Get -99999.9999 to 99999.9999
500 + N × 1
(N = 0 to 99)
Actual coordinate Y for Point N
(p
oint specificatio
n)
Set/Get -99999.9999 to 99999.9999
600 + N × 1
(N = 0 to 99)
Camera coordinate X for sampling
N
(sampling)
Set/Get 0.0000 to 99999.9999
700 + N × 1
(N = 0 to 99)
Camera coordinate Y for sampling
N
(sampling)
Set/Get 0.0000 to 99999.9999
800 + N × 1
(N = 0 to 99)
Actual coordinate X for sampling N
(sampling)
Set/Get -99999.9999 to 99999.9999
900 + N × 1
(N = 0 to 99)
Actual coordinate Y for sampling N
(sampling)
Set/Get
-99999.9999 to 99999.9999
No. Data name Set/Get Data range
