IntersectionFH/FZ5 Processing Item Function Reference Manual
303
2
Inspecting and Measuring
31 Peak edge position Y of line 1 Get only 0.0000 to 99999.9999
32 Bottom edge position X of line 1 Get only 0.0000 to 99999.9999
33 Bottom edge position Y of line 1 Get only 0.0000 to 99999.9999
34 Edge position X Ave. of line 1 Get only -1.0000 to 99999.9999
35 Edge position Y Ave. of line 1 Get only -1.0000 to 99999.9999
36 Long distance Max. of line 1 Get only -1.0000 to 99999.9999
37 Long distance Min. of line 1 Get only -1.00000 to 99999.9999
38 Short distance Max. of line 1 Get only -1.0000 to 99999.9999
39 Short distance Min. of line 1 Get only -1.0000 to 99999.9999
40 Deviation of line 1 Get only -1.0000 to 99999.9999
41 Angle of line 1 Get only -180 to 180
42 Lost point count of line 1 Get only 0 to 100
43 Linear coefficient A of line 1 Get only -99999.9999 to 99999.9999
44 Linear coefficient B of line 1 Get only -99999.9999 to 99999.9999
45 Linear coefficient C of line 1 Get only -99999.9999 to 99999.9999
101 Output Coordinates Set/Get
0: After scroll
1: Before scroll
102 Calibration Set/Get
0: OFF
1: ON
103 Reflect to overall judgement Set/Get
0: ON
1: OFF
120 Reference X
*2
Set/Get 0.0000 to 99999.9999
121 Reference Y
*2
Set/Get 0.0000 to 99999.9999
122
Share setting (Edge color
sp
ecification
)
Set/Get
0: Not shared
1: Shared
123
Share setting (Measurement
p
arameter)
Set/Get
0: Not shared
1: Shared
124 Line number currently selected Set/Get
0: Line 0
1: Line 1
130
Upper limit of intersection X
co
ordin
ate
Set/Get -99999.9999 to 99999.9999
131
Lower limit of intersection X
co
ordin
ate
Set/Get -99999.9999 to 99999.9999
132
Upper limit of intersection Y
co
ordinate
Set/Get -99999.9999 to 99999.9999
133
Lower limit of intersection Y
co
ordinate
Set/Get -99999.9999 to 99999.9999
134 Angle upper limit Set/Get 0 to 180
135 Angle lower limit Set/Get 0 to 180
136 Upper limit of lost point count (line 0) Set/Get 0 to 100
137 Lower limit of lost point count (line 0) Set/Get 0 to 100
138 Upper limit of lost point count (line 1) Set/Get 0 to 100
139 Lower limit of lost point count (line 1) Set/Get 0 to 100
200 Edge color specification (line 0) Set/Get
0: No color specification
1: With color specification
No. Data name Set/Get Data range
