ClassificationFH/FZ5 Processing Item Function Reference Manual
223
2
Inspecting and Measuring
122
Upper limit of the rotation
angl
e
Set/Get -180 to 180
123
Lower limit of the rotation
a
ngl
e
Set/Get -180 to 180
124 Skipping angle Set/Get 1 to 30
125 Smart mode Set/Get
0: OFF
1: ON
126 Stab. (CR) Set/Get 1 to 15
127 Prec. Set/Get 1 to 3
128 Stab. (PT) Set/Get 1 to 5
134 Sub-pixel Set/Get
0: OFF
1: ON
135 Candidate Point Level Set/Get 0 to 100
136 Upper limit of measure X Set/Get -99999.9999 to 99999.9999
137 Lower limit of measure X Set/Get -99999.9999 to 99999.9999
138 Upper limit of measure Y Set/Get -99999.9999 to 99999.9999
139 Lower limit of measure Y Set/Get -99999.9999 to 99999.9999
140 Upper limit of the angle Set/Get -180 to 180
141 Lower limit of the angle Set/Get -180 to 180
142 Upper limit of the corr. Set/Get 0 to 100
143 Lower limit of the corr. Set/Get
0 to 100
No. Data name Set/Get Data range
