Omron fh-3 series User Manual

Extract Color FilterFH/FZ5 Processing Item Function Reference Manual
531
3
Compensate image
131 + 10 × N
(N = 0 to 7)
OR/NOT setting [N]
(N = 0 to 7)
Set/Get
0: OR
1: NOT
132 + 10 × N
(N = 0 to 7)
Register the max. color hue
[N]
(N = 0 to 7)
Set/Get 0 to 359
133 + 10 × N
(N = 0 to 7)
Register the min. color hue
[N]
(N = 0 to 7)
Set/Get 0 to 359
134 + 10 × N
(N = 0 to 7)
Register the max. color
sat
u
ration [N]
(N = 0 to 7)
Set/Get 0 to 255
135 + 10 × N
(N = 0 to 7)
Register the min. color
sat
uration [N]
(N = 0 to 7)
Set/Get 0 to 255
136 + 10 × N
(N = 0 to 7)
Register the max. color
br
ightness [N]
(N = 0 to 7)
Set/Get 0 to 255
137 + 10 × N
(N = 0 to 7)
Register the min. color
br
ightness [N]
(N = 0 to 7)
Set/Get 0 to 255
138 + 10 × N
(N = 0 to 7)
Register the BG color [N]
(N = 0 to 7)
Set/Get
0: Black
1 : White
2: Red
3: Green
4: Blue
5000
RGB value pixel density
dat
a
Set/Get
Characteristic application
The RGB value for the coordinate specified during set up is
saved in measu
r
ement data.
When acquiring, the data saved in measurement data is
retu
rned.
5001
Selected
color extraction
range
Set/Get
Characteristic application
The color extraction range number selected during set up is
saved in measu
r
ement data.
When acquiring, the data saved in measurement data is
returned.
No. Data name Set/Get Data range
