Labeling
348
FH/FZ5 Processing Item Function Reference Manual
137 Label No. Set/Get
0 to 2499 (For FZ5-3xx, FZ5-6xx)
0 to 9998 (For FH-1xxx, FH-3xxx, FZ5-8xx, FZ5-11xx,
FZ5-12xx)
138
Upper limit of the number of
labels
Set/
Get
0 to 2500 (For FZ5-3xx, FZ5-6xx)
0 to 9999 (For FH-1xxx, FH-3xxx,
FZ5-8x
x, FZ5-11xx,
FZ5-12xx)
139
Lower limit of the number of
labe
ls
Set/
Get
0 to 2500 (For FZ5-3xx, FZ5-6xx)
0 to 9999 (For FH-1xxx, FH-3xxx,
FZ5-8x
x, FZ5-11xx,
FZ5-12xx)
140 Upper limit of the area Set/Get 0 to 999999999.9999
141 Lower limit of the area Set/Get 0 to 999999999.9999
142 Upper limit of the gravity X Set/Get -99999.9999 to 99999.9999
143 Lower limit of the gravity X Set/Get -99999.9999 to 99999.9999
144 Upper limit of the gravity Y Set/Get -99999.9999 to 99999.9999
145 Lower limit of the gravity Y Set/Get -99999.9999 to 99999.9999
146
Upper limit of the binary level
(for monochrome cameras
only)
Set/Get 0 to 255
147
Lower limit of the binary level
(for monochrome cameras
only)
Set/Get 0 to 255
148
Binary image
(for monochrome cameras
only)
Set/Get
0: OFF
1: ON
149 Image kind Set/Get
0: Measurement image
1: All color image
2: Selection color image
3: Binary image
150 Multiple selections Set/Get
0: Multiple selections disabled
1: Multiple selections enabled
154 Label maximum Set/Get 1 to 9999
160 + N
*3
× 10
Flag N
*3
used for registered
color
Set/Get
0: Not used
1 : Used
161 + N
*3
× 10
Flag N
*3
for registered color
OR/NOT
Set/Get
0: OR
1: NOT
162 + N
*3
× 10
Register the max. color hue
N
*3
Set/Get 0 to 359
163 + N
*3
× 10 Register the min. color hue N
*3
Set/Get 0 to 359
164 + N
*3
× 10
Register the max. color
saturation N
*3
Set/Get 0 to 255
165 + N
*3
× 10
Register the min. color
saturation N
*3
Set/Get 0 to 255
166 + N
*3
× 10
Register the max. color
br
ightness N
*3
Set/Get 0 to 255
167 + N
*3
× 10
Register the min. color
br
ightness N
*3
Set/Get 0 to 255
No. Data name Set/Get Data range
