LabelingFH/FZ5 Processing Item Function Reference Manual
349
2
Inspecting and Measuring
168 + N
*3
× 10 Background color N
*3
Set/Get
0: Black
1 : White
2: Red
3: Green
4: Blue
301
Setting unit of reference
coordi
nate
Set/Get -1 to 9999
302
Setting type of reference
coordi
nate
Set/Get
0: Numerical
1: Unit
303
Use point coordinate before
sc
roll
Set/Get
0: Not use
1: Use
304 Position X before scroll Set/Get -99999.9999 to 99999.9999
305 Position Y before scroll Set/Get -99999.9999 to 99999.9999
311 Region reverse Set/Get
0: Not reverse
1: Reverse
312 Dilate erosion level Set/Get -10 to 10
313 Static mask type Set/Get
0: Region extract
1: Region of image reference
314 Static mask unit reference no Set/Get -1 to 9999
315 Static mask image no Set/Get 0 to 99
316
Dynamic mask unit reference
no
Set/Get -1 to 9999
317 Dynamic mask image no Set/Get 0 to 99
318 Mask type Set/Get
0: Static mask
1: Dynamic mask
319 Display image type Set/Get
0: Measure image
1: Mask binary image
2: Mask and image
324 Is mask Set/Get
0: OFF
1: ON
325 Mask region display color Set/Get
0: Black
1: White
2: Red
3: Green
4: Blue
501 + N
*3
× 10 Extraction condition N
*3
Set/Get
0: OFF
1: Area
2: Gravity X
3: Gravity Y
4: Elliptical approximate major axis
5: Elliptical approximate minor axis
6: Ratio for flat approximate ellipse
7: Width of circumscribed rectangle
8: Height of circumscribed rectangle
9: Rectangle X1
10: Rectangle Y1
503 + N
*3
× 10
Extraction condition upper limit
N
*3
Set/Get -999999999.9999 to 999999999.9999
504 + N
*3
× 10
Extraction condition lower limit
N
*3
Set/Get -999999999.9999 to 999999999.9999
No. Data name Set/Get Data range
