Labeling
350
FH/FZ5 Processing Item Function Reference Manual
*1: The reference coordinates based on the selection in the Method area of the [Ref.setting] tab can be Get only.
*2: The reference coordinates based on the selection of Numerical in the Method area of the [Ref.setting] tab can be Set/Get.
*3: N = 0 - 2 (Extraction condition 0 to 2)
*4: N = 0 - 7 (Judgement condition 0 to 7)
*5: N = 0 - 99
600 + N
*4
× 10 Judgement condition N
*4
Set/Get
0: OFF
1: Number of labels
2: Total area
3: Area
4: Gravity X
5: Gravity Y
6: Elliptic axis angle
7: Elliptical approximate major axis
8: Elliptical approximate minor axis
9: Ratio for flat approximate ellipse
10: Width of circumscribed rectangle
11: Height of circumscribed rectangle
12: Upper left X coordinate of circumscribed rectangle
13: Upper left Y coordinate of circumscribed rectangle
601 + N
*4
× 10
Judgement condition display
flag N
*4
Set/Get
0: OR
1: NOT
602 + N
*4
× 10
Judgement condition upper
limit N
*4
Set/Get -999999999.9999 to 999999999.9999
603 + N
*4
× 10
Judgement condition lower
limit N
*4
Set/Get -999999999.9999 to 999999999.9999
1000 + N
*5
Feature data Set/Get -999,999,999.9999 to +999,999,999.9999
1100 + N
*5
Feature data Set/Get -999,999,999.9999 to +999,999,999.9999
1200 + N
*5
Feature data Set/Get -999,999,999.9999 to +999,999,999.9999
1300 + N
*5
Feature data Set/Get -999,999,999.9999 to +999,999,999.9999
1400 + N
*5
Feature data Set/Get -999,999,999.9999 to +999,999,999.9999
1500 + N
*5
Feature data Set/Get -999,999,999.9999 to +999,999,999.9999
1600 + N
*5
Feature data Set/Get -999,999,999.9999 to +999,999,999.9999
1700 + N
*5
Feature data Set/Get -999,999,999.9999 to +999,999,999.9999
6002 Format Set/Get
1: monochrome camera
2: color camera
No. Data name Set/Get Data range
