Scan Edge Position
256
FH/FZ5 Processing Item Function Reference Manual
131 Edge No. Set/Get 0 to 99
132 Edge level lower limit Set/Get 0 to 100
133 Noise level Set/Get
Color camera: 0 to 442
Monochrome camera: 0 to 255
134 Noise width Set/Get 0 to 9999
135 Edge color level Set/Get 0 to 442
136
Upper limit of the maximum
e
dge position X
Set/Get -99999.9999 to 99999.9999
137
Lower limit of the maximum
e
dge position X
Set/Get -99999.9999 to 99999.9999
138
Upper limit of the maximum
e
dge
position Y
Set/Get -99999.9999 to 99999.9999
139
Lower limit of the maximum
e
dge position Y
Set/Get -99999.9999 to 99999.9999
140
Upper limit of the minimum
e
dge position X
Set/Get -99999.9999 to 99999.9999
141
Lower limit of the minimum
e
dge
position X
Set/Get -99999.9999 to 99999.9999
142
Upper limit of the minimum
e
dge position Y
Set/Get -99999.9999 to 99999.9999
143
Lower limit of the minimum
e
dge position Y
Set/Get -99999.9999 to 99999.9999
144
Upper limit of the edge
p
o
sition X Ave.
Set/Get -99999.9999 to 99999.9999
145
Lower limit of the edge
p
osition X Ave.
Set/Get -99999.9999 to 99999.9999
146
Upper limit of the edge
p
osition Y Ave.
Set/Get -99999.9999 to 99999.9999
147
Lower limit of the edge
p
o
sition Y Ave.
Set/Get -99999.9999 to 99999.9999
148
Upper limit of the long
dist
ance Max.
Set/Get 0 to 99999.9999
149
Lower limit of the long
dist
ance Max.
Set/G
et 0 to 99999.9999
150
Upper limit of the short
distance Max.
Set/G
et 0 to 99999.9999
151
Lower limit of the short
dist
ance Max.
Set/Get 0 to 99999.9999
152 Upper limit of the deviation Set/Get 0 to 99999.9999
153 Lower limit of the deviation Set/Get 0 to 99999.9999
154 Upper limit of the angle Set/Get -180 to 180
155 Lower limit of the angle Set/Get -180 to 180
156 Upper limit of the lost point Set/Get 0 to 100
157 Lower limit of the lost point Set/Get 0 to 100
158
Monochrome edge
detection mode
Set/Get
0: Light→Dark
1: Dark→Light
No. Data name Set/Get Data range
