Scan Edge PositionFH/FZ5 Processing Item Function Reference Manual
257
2
Inspecting and Measuring
*1: The reference coordinates based on the selection in the Method area of the [Ref.setting] tab can be Get only.
*2: The reference coordinates based on the selection of Numerical in the Method area of the [Ref.setting] tab can be Set/Get.
*3: On the [Measurement] tab of the Properties Dialog Box, this data is displayed as [Edge Upper] when you choose the [Position
(%) for w
idth of a color].
*4: On the [Measurement] tab of the Properties Dialog Box, this data is displayed as [Edge Upper] when you choose the [Value
(442
at the maximum) of color].
159
Edge level lower limit
absolute value
Set/Get 0 to 442
160
Edge level specification
method
Set/Get
0: %
1: Absolute value
162 Scan sub-region Set/Get 1 to 100
163 Mask size Set/Get 0 to 200
164 Display area Set/Get 0 to 99
165 Noise cancel Set/Get
0: OFF
1: ON
166 Measure type Set/Get
0: Projection
1: Differential
167 Fix region count Set/Get
0: Not fixed
1: Fixed
168 Edge level upper limit
*3
Set/Get 0 to 100
169
Edge level upper limit
absolute value
*4
Set/Get 0 to 442
170
Monochrome Derivation
edge detection mode
Set/Get 0 to 2
171 FNC Rate Set/Get 0 to 100
177 Filter Strength Set/Get 0 to 100
178
Setting unit of reference
co
ordinate
Set/Get -1 to 9,999
179
Setting type of reference
co
ordinate
Set/Get
0: Numerical
1: Unit
180
Use point coordinate
be
fore scroll
Set/Get
0: Not use
1: Use
181 Position X before scroll Set/Get -99999.9999 to 99999.9999
182 Position Y before scroll Set/Get -99999.9999 to 99999.9999
6002 Format Set/Get
1: monochrome camera
2: color camera
