Color DataFH/FZ5 Processing Item Function Reference Manual
315
2
Inspecting and Measuring
6
Average G component
value
Get only 0 to 255
7
Average B component
value
Get only 0 to 255
8 Color difference Get only 0 to 442
9 Color deviation Get only 0 to 221
10
Density average
(for monochrome cameras
on
l
y)
Get only 0 to 255
11
Density deviation value
(for monochrome cameras
onl
y)
Get only 0 to 127
12 Reference average value Get only 0 to 255
13 Reference deviation value Get only 0 to 127
14 Density average difference Get only 0 to 255
15
Density deviation
d
i
fference
Get only 0 to 127
16 H average value Get only 0 to 359
17 S average value Get only 0 to 255
18 V average value Get only 0 to 255
103
Reflect to overall
judg
ement
Set/Get
0: ON
1: OFF
120 Normalization Set/Get
0: OFF
1: ON
121 Reference color R Set/Get 0 to 255
122 Reference color G Set/Get 0 to 255
123 Reference color B Set/Get 0 to 255
124
Upper limit for color
d
i
fference
Set/Get 0 to 442
125
Lower limit for color
d
i
fference
Set/Get 0 to 442
126
Upper limit for color
deviation
Set/Get 0 to 221
127
Lower limit for color
deviation
Set/Get 0 to 221
128 Reference density average Set/Get 0 to 255
129
Reference density
deviation
Set/Get 0 to 127
130
Upper limit for density
a
verage
(for monochrome cameras
on
l
y)
Set/Get 0 to 255
131
Lower limit for density
average
(for monochrome cameras
on
l
y)
Set/Get
0 to 255
No. Data name Set/Get Data range
