2D CodeFH/FZ5 Processing Item Function Reference Manual
423
2
Inspecting and Measuring
Communication output
• [RS-232C/
RS-422]
• Ethernet
Set the output destination.
When Ethernet is selected, the de
stination IP address is
determined by the system settings.
Reference:  Non
-procedure Communications in the Vision
System
FH/FZ5 Series User’s Manual for Communications
Settings (Cat. No. Z342).
Header
• [None]
•STX
• ESC
Set the header of communication output.
Footer
•[CR]
• CR+LF
•ETX
•LF
Set the footer of communication output.
FCS
• Available
• [None]
Set whether to output FCS (frame check sequence).
FCS performs an XOR of each byte
from th
e beginning to the
end of data and converts the result (8 bits) into two ASCII
format characters.
The reliability of communication can be increased by adding
F
CS to the output data.
Reading character output
Reading character
ou
tput
• [Checked]
• Unchecked
Set whether to output character strings.
Output range specify
•Checked
• [Unchecked]
Set when specifying the range of
character strings to be
output. This can be set to a range of 1 to 652.
Output range specify
1 to 652
[1] to [652]
Specify the range of output character coun
t. Th
is can be set to
a range of 1 to 652.
Character count output
•Checked
• [Unchecked]
Specify whether to output the cha
racter count of the character
string.
Character code size
• [2bytes]
• 4bytes
Select the character code size for
char
acter output.
Code quality output
• [Checked]
• Unchecked
The setting is enabled if you select [DPM] for the measurement
p
arameter read mode.
Set whether to output the 2D Code quality.
Output when reading error
occurs
Error character output
•Checked
• [Unchecked]
Specify whether to output the specified character string when
the
re is a reading error. If a check is placed, the character
string entered in the lower frame is output.
Up to 20 characters can be input.
Error code output
•Checked
• [Unchecked]
Set whether to output error codes.
Error codes are as follows:
0: Normal termination
-1: 2D Code not found
-3: Timeout
-7: Processing terminated due to too much data
Setting item
Set value
[Factory default]
Description
