PLC Master CalibrationFH/FZ5 Processing Item Function Reference Manual
775
4
Support Inspection and Measurement
*1: If you set the external reference table and execute the applicable Processing unit item, confirm the current Processing unit item
is same as the selected Scene.
1001 + N × 10
(N: 0 to 99)
Y-direction movement of parallel position
No.N
Set/Get -999,999,999.9999 to 999,999,999.9999
2000 + N × 10
(N: 0 to 99)
X-direction movement of rotation position
No
.N
Set/
Get -999,999,999.9999 to 999,999,999.9999
2001 + N × 10
(N: 0 to 99)
Y-direction movement of rotation position
No
.N
Set/Get -999,999,999.9999 to 999,999,999.9999
2002 + N × 10
(N: 0 to 99)
TH-direction movement of rotation
po
sition No.N
Set/Get -180.0000 to 180.0000
5000 Calibration start/end Set only
0: Calibration end
1: Calibration start
5001 Set calibration target Set only 0 to 255
5002 *1 Set standard position Set only 1 to 1
5003 Set parallel position Set only 1 to 100
5004 Set rotation position Set only 1 to 100
5005 *1 Calculate calibration data Set only 1: Execute
5006 *1 Calculate deflection data Set only 1: Execute
5007 *1 Clear sampling data Set only 1: Clear
5009 *1 Clear step counter Set only 1: Clear
14000 + N × 10000
(N: 0 to 7)
Deflection of dataN Get only ---
14001 + N × 1
0000
(N: 0 to 7)
Calibration parameter A of dataN Set/Get -999,999,999.9999 to 999,999,999.9999
14002 + N × 1
0000
(N: 0 to 7)
Calibration parameter B of dataN Set/Get -999,999,999.9999 to 999,999,999.9999
14003 + N × 1
000
0
(N: 0 to 7)
Calibration parameter C of dataN Set/Get -999,999,999.9999 to 999,999,999.9999
14004 + N × 1
0000
(N: 0 to 7)
Calibration parameter D of dataN Set/Get -999,999,999.9999 to 999,999,999.9999
14005 + N × 1
000
0
(N: 0 to 7)
Calibration parameter E of dataN Set/Get -999,999,999.9999 to 999,999,999.9999
14006 + N × 1
000
0
(N: 0 to 7)
Calibration parameter F of dataN Set/Get -999,999,999.9999 to 999,999,999.9999
14007 + N × 1
000
0
(N: 0 to 7)
X magnification of dataN Get only ---
14008 + N × 1
000
0
(N: 0 to 7)
Y magnification of dataN Get only ---
14009 + N × 1
0000
(N: 0 to 7)
Origin X of dataN Get only ---
14010 + N × 1
0000
(N: 0 to 7)
Origin Y of dataN Get only ---
14011 + N × 1
0000
(N: 0 to 7)
X-axis angle of dataN Get only ---
14012 + N × 1
0000
(N: 0 to 7)
Y-axis angle of dataN Get only ---
14013 + N × 1
0000
(N: 0 to 7)
XY-axis angle of dataN Get only -
--
