Character Inspection
400
FH/FZ5 Processing Item Function Reference Manual
1000+N
(N=0 to 31)
Unit No. Get only
-1: None
0 to 9999
1032+N
(N=0 to 31)
Detected index Get only 0 to 35
1064+N
(N=0 to 31)
Detected model No. Get only 0 to 4
1096+N
(N=0 to 31)
Chara. code Get only 0 to 0xFFFF (UTF-16 code)
1128+N
(N=0 to 31)
Detected NG cause Get only 0 to 15
1160+N
(N=0 to 31)
Correlation value Get only 0 to 100
1192+N
(N=0 to 31)
Detected coordinate X Get only -99999.9999 to 99999.9999
1224+N
(N=0 to 31)
Detected coordinate Y Get only -99999.9999 to 99999.9999
1256+N
(N=0 to 31)
Detected angle Get only -180 to 180
1288+N
(N=0 to 31)
Reference X Get only -99999.9999 to 99999.9999
1320+N
(N=0 to 31)
Reference Y Get only -99999.9999 to 99999.9999
1352+N
(N=0 to 31)
Reference angle Get only -180 to 180
1384+N
(N=0 to 31)
Detected scene No. Get only
-1: Current scene
0 to 9999
1416+N
(N=0 to 31)
Second correlation value Get only 0 to 100
1448+N
(N=0 to 31)
Second index No. Get only 0 to 35
1480+N
(N=0 to 31)
Stability Get only
0 to 100
No. Data name Set/Get Data range
