Shape Search III
182
FH/FZ5 Processing Item Function Reference Manual
Confirm the measurement result on the display (Display setting)
1 Set the check box in the Display setting area.
2 Confirm the measurement processing condition, then set Measurement condition.
Set Judgment condition
Set the upper and lower values to judge the measurement result. When the measurement result value is within
the upper and lower value, Judgment is [OK] (pass). When the measurement result value exceeds either the
upper, or lower value Judgment is [NG] (failed). About The Judgment result for the Processing Unit is [OK] when
the judgment for all measurements is [OK], however it will be [NG] if any measurement result is [NG].
1 Set the value in the Judgment area.
Setting item
Setting value
[Factory default]
Description
Display edge
•Checked
• [Unchecked]
Check this item when you confirm extracted edge set in
[Edge level
] on the display.
Display corresponding
model
•Checked
• [Unchecked]
Check this item when you confirm detected Model on the
display.
Setting item
Setting value
[Factory default]
Description
Count
0 to 128
[0] to [32]
Set the upper and lower values of number of detected
Model.
Measure X
-99999.9999 to 99999.9999
[-99999.9999] to [99999.9999]
Set the upper and lower values of detected Model on X
coordi
nate.
Measure Y
-99999.9999 to 99999.9999
[-99999.9999] to [99999.9999]
Set the upper and lower values of detected Model on Y
coordi
nate.
Search angle
-180 to 180
[-180] to [180]
Set the upper and lower values of detected Model angle.
Correlation
0 to 100
[60] to [100]
Set the upper and lower correlation values of detected
Mo
del
.
Judgment will be [NG] instead of the lower value when the
me
asuremen
t result correlation is zero.
• Measurement result will be displayed on the right of the Ju
dgment items. You can set the Judgment condition
refer to this value.
Note
