Edge Position
234
FH/FZ5 Processing Item Function Reference Manual
*1: The reference coordinates based on the selection in the Method area of the [Ref.setting] tab can be Get only.
*2: The reference coordinates based on the selection of Numerical in the Method area of the [Ref.setting] tab can be Set/Get.
*3: On the [Measurement] tab of the Properties Dialog Box, this data is displayed as [Edge Upper] when you choose the [Position
(%) for w
idth of a color].
*4: On the [Measurement] tab of the Properties Dialog Box, this data is displayed as [Edge Upper] when you choose the [Value
(442
at the maximum) of color].
141 Edge level absolute value Set/Get
Color camera: 0 to 442
Monochrome camera: 0 to 255
142
Edge level specification
method
Set/Get
0: %
1: Absolute value
143
Clockwise/
C
ounterclockwise
Set/Get
0: Clockwise
1: Counterclockwise
144 Measure type Set/Get
0: Projection
1: Derivation
145
Monochrome Projection
e
dge
detection mode
Set/Get
0: Absolute
1: Dark→Li
ght
2
: Light→Dark
146 Edge Level Upper limit
*3
Set/Get 0 to 100
147
Edge level Upper limit
absolute value
*4
Set/Get
Color camera: 0 to 442
Monochrome camera: 0 to 255
148 Filter Strength Set/Get 0 to 100
158
Setting unit of reference
co
ordin
ate
Set/Get -1 to 9999
159
Setting type of reference
co
ordinate
Set/Get
0: Numerical
1: Unit
160
Use point coordinate
be
fo
re scroll
Set/Get
0: Not use
1: Use
161 Position X before scroll Set/Get -99999.9999 to 99999.9999
162 Position Y before scroll Set/Get -99999.9999 to 99999.9999
6002 Format Set/Get
1: monochrome camera
2: color camera
