Barcode
446
FH/FZ5 Processing Item Function Reference Manual
Output of Character string with Non-procedure Communications
Check the [Character output] in Output parameter to output the character string with Non-procedure
communication.
Reference: Output Parameters (Barcode) (p.442)
1 Output Format
Take the following case as an example. Number of measurement is one.
Reading character string is 32. Read character strings 0123456789… UV, Command, Response, and
Data
Output area are as follows.
In this case, the following conditions are applied.
[Reading character output] is checked.
[Character count output] and [Error character output] are unchecked.
Reference: Non-procedure Communications and MEASURE
or M in Non-procedure Command Details
in
Vision System FH/FZ5 Series User’s Manual for Communications Settings (Z342).
Command (PLC to Sensor Controller)
Response (Sensor Controller to PLC)
.
• If [Error output] is not checked and no character string, refer to the following.
• If [Error output] is checked and no character string, refer to the following.
MUAES E
RM
or
C
R
C
R
0123456789…UV(Character string data)
C
R
O
C
R
K
Note
O
C
R
K
C
R
(Error character string data)
C
R
O
C
R
K
