FH/FZ5 Processing Item Function Reference Manual
Setting Judgement Conditions Individually by Character
Set judgement conditions for all characters individually by character.
1 In the judgement condition area, click [Detail setting].
The individual judgement condition area appears.
2 Set the items in the individual judgement condition area.
Verification
limits 1
•[Unchecked]
• Checked
The setting is enabled if [OCV] is specified for the inspection mode
an
d [Un
it] is specified for the OCV condition.
Click on the [Verification limits 1] c
h
eckbox to turn it ON to verify
the character string on the first line.
1 to 1024
[1] to [1024]
The setting is enabled if [OCV] is specified for the inspection
mode,
[Unit] is specified for the OCV condition, and the
[Verification limits 1] checkbox is checked.
Set the range for the character string that is to be used as the
cha
racter verification string on the first line of the measurement
results for the processing unit specified by the reference unit.
Verification
limits 2
•[Unchecked]
• Checked
The setting is enabled if [OCV] is specified for the inspection mode
an
d [Un
it] is specified for the OCV condition.
Click on the [Verification limits 2] c
h
eckbox to turn it ON to verify
the character string on the second line.
1 to 1024
[1] to [1024]
The setting is enabled if [OCV] is specified for the inspection
mode,
[Unit] is specified for the OCV condition, and the
[Verification limits 2] checkbox is checked.
Set the range for the character string that is to be used as the
cha
racter verification string on the second line of the
measurement results for the processing unit specified by the
reference unit.
Verification
limits 3
•[Unchecked]
• Checked
The setting is enabled if [OCV] is specified for the inspection mode
an
d [Un
it] is specified for the OCV condition.
Click on the [Verification limits 3] c
h
eckbox to turn it ON to verify
the character string on the third line.
1 to 1024
[1] to [1024]
The setting is enabled if [OCV] is specified for the inspection
mode,
[Unit] is specified for the OCV condition, and the
[Verification limits 3] checkbox is checked.
Set the range for the character string that is to be used as the
cha
racter verification string on the third line of the measurement
results for the processing unit specified by the reference unit.
Verification
limits 4
•[Unchecked]
• Checked
The setting is enabled if [OCV] is specified for the inspection mode
an
d [Un
it] is specified for the OCV condition.
Click on the [Verification limits 4] c
h
eckbox to turn it ON to verify
the character string on the fourth line.
1 to 1024
[1] to [1024]
The setting is enabled if [OCV] is specified for the inspection
mode,
[Unit] is specified for the OCV condition, and the
[Verification limits 4] checkbox is checked.
Set the range for the character string that is to be used as the
character verification string on the fourth line of the measurement
results for the processing unit specified by the reference unit.
Setting item
Setting value
[Factory default]
Description
