Background SuppressionFH/FZ5 Processing Item Function Reference Manual
519
3
Compensate image
3 Set the background suppression level.
There are two setting methods: specifying the section in the image whose contrast is to be emphasized or
specifying the extraction range with numeric values.
For color cameras:
For monochrome cameras:
4 As necessary, set the display image.
Item
Set value
[Factory default]
Description
Suppression level
RGB common
0 to 255
The upper and lower limits for the background suppression level
are
set in common for RGB. The range from the set minimum to
the set maximum is converted to 0 to 255.
RGB individual
0 to 255
The maximum and minimum for the background suppression level
are
independently for RGB. The range from the set minimum to
the set maximum is converted to 0 to 255.
Setting item
Set value
[Factory default]
Description
Gray 0 to 255 The set range is converted to 0 to 255.
To Next Page
