Stage DataFH/FZ5 Processing Item Function Reference Manual
739
4
Support Inspection and Measurement
170 U-axis direction Set/Get
0: X-axis positive
1: X-axis negative
2: Y-axis positive
3: Y-axis negative
171 V-axis direction Set/Get
0: X-axis positive
1: X-axis negative
2: Y-axis positive
3: Y-axis negative
172 W-axis direction Set/Get
0: X-axis positive
1: X-axis negative
2: Y-axis positive
3: Y-axis negative
173 R-axis direction Set/Get
0: X-axis positive
1: X-axis negative
2: Y-axis positive
3: Y-axis negative
180 Lower limit of X-axis movement Set/Get -99,999.999999 to 99,999.999999
181 Upper limit of X-axis movement Set/Get -99,999.999999 to 99,999.999999
182 Lower limit of Y-axis movement Set/Get -99,999.999999 to 99,999.999999
183 Upper limit of Y-axis movement Set/Get -99,999.999999 to 99,999.999999
184 Lower limit of θ-ax
i
s movement Set/Get -180.0000 to 180.0000
185 Upper limit of θ-axi
s movement Set/Get -180.0000 to 180.0000
186 Lower limit of θ-axi
s(linear drive) movement Set/Get -99,999.999999 to 99,999.999999
187 Upper limit of θ-axi
s(linear drive) movement Set/Get -99,999.999999 to 99,999.999999
190 Lower limit of U-axis movement Set/Get -99,999.999999 to 99,999.999999
191 Upper limit of U-axis movement Set/Get -99,999.999999 to 99,999.999999
192 Lower limit of V-axis movement Set/Get -99,999.999999 to 99,999.999999
193 Upper limit of V-axis movement Set/Get -99,999.999999 to 99,999.999999
194 Lower limit of W-axis movement Set/Get -99,999.999999 to 99,999.999999
195 Upper limit of W-axis movement Set/Get -99,999.999999 to 99,999.999999
196 Lower limit of R-axis movement Set/Get -99,999.999999 to 99,999.999999
197 Upper limit of R-axis movement Set/Get -99,999.999999 to 99,999.999999
300 Movement axis Set/Get
0: X-axis
1: Y-axis
301 Coordinate Set/Get
0: Lefthand
1: Righthand
302 relative angle Set/Get 1.000000 to 179.000000
303 relative magnification Set/Get
0.100000 to 9.999999
