Control Flow Parallel
854
FH/FZ5 Processing Item Function Reference Manual
3 In the “DO Signal Setting” area, specify a value for each item.
Setting item
Setting value
[Factory default]
Description
Use timeout
• [Checked]
• Unchecked
If you want to clear the measurement flow wait state
afte
r a certain period of time elapses, select the “Use
timeout” check box.
This should normally be used with the check box
selec
ted.
Setting time
0 to 120,000
[5,000]
This item can be set when the [Use timeout] check box
is selected.
Set the time in ms after which the wait state on the
proce
s
sing unit is cleared.
When a timeout is used, the wa
it st
ate is cleared when
the time set in “Setting time” elapses after the
measurement unit starts measurement processing.
When the wait state is cleared, the measurement flow
resumes.
Unit judgement in timeout
•[NG]
•OK
This item can be set when the [Use timeout] check box
is selected.
Select whether the judgement result of the processing
uni
t is NG or OK whe
n the processing unit times out
after the “Setting time” in measurement processing.
• Normally the “Use timeout” check box should be selected. Wh
en the check mark is removed from “Use timeout”,
the wait state can only be cleared by executing a “Wait state clear command” from an external device.
Setting item
Setting value
[Factory default]
Description
Wait signal
• [Checked]
• Unchecked
To use a DO signal as a Flow Command Wait
sig
nal, select the “WAIT signal” (a signal
indicating that a command is available during a
flow) checkbox.
This should normally be used with the check box
selected.
Signal No.
DO0 to DO15
[DO0]
Set the signal that is used as a WAIT signal.
The signal set here can be used as a Flow
Co
mma
nd Wait signal.
FLG signal
• [Checked]
• Unchecked
To use a DO signal as a Flow Command
Co
mpletio
n signal, select the “FLG signal” (a
signal indicating a flow command completion)
checkbox.
This should normally be used with the check box
selected.
Signal No.
DO0 to DO15
[DO1]
Set the signal that is used as the FLG signal.
The signal set here can be used as a Flow
Co
mma
nd Completion signal.
• If the same signal is set for the WAIT signal and the FLG signal, a “Same Signals are Assigned” error message
will
appear. Assign different signals for each.
To Next Page
