Ec Corner
200
FH/FZ5 Processing Item Function Reference Manual
137
Line 0 condition
Lower limit of overrun range
Set/Get -1000 to 1000
138
Line 0 condition
Upper limit of overrun range
Set/Get -1000 to 1000
139
Line 1 condition
Lower limit of overrun range
Set/Get -1000 to 1000
140
Line 1 condition
Upper limit of overrun range
Set/Get -1000 to 1000
141 Detection object color Set/Get
0: Both
1: Corner (dark) - Background (light)
2: Corner (light) - Background (dark)
149 Sort order Set/Get
0: Cross point X
1: Cross point Y
2: Line length
150 Sort sequence Set/Get
0: Ascending
1: Descending
151 Output number Set/Get 0 to 99
155 With/without intersection fusion Set/Get
0: OFF
1: ON
156 Fusion distance Set/Get 0 to 1000
157 Fusion line angle range Set/Get 0 to 20
158 Fusion corner angle range Set/Get 0 to 20
159 Intersection fusion condition Set/Get
0: Priority on line length
1: Priority on distance from intersection
2: Priority on corner angle
160
Judgement condition: Lower
limit
of
corner X
Set/Get -99999.9999 to 99999.9999
161
Judgement condition: Upper
limit
of corner X
Set/Get -99999.9999 to 99999.9999
162
Judgement condition: Lower
limit
of
corner Y
Set/Get -99999.9999 to 99999.9999
163
Judgement condition: Upper
limit
of
corner Y
Set/Get -99999.9999 to 99999.9999
164
Judgement condition: Lower
limit of
angle
Set/Get 0 to 360
165
Judgement condition: Upper
limit of
angle
Set/Get 0 to 360
166
Judgement condition: Lower
l
imit of number of detections
Set/Get 0 to 100
167
Judgement condition: Upper
l
imit of number of detections
Set/Get 0 to 100
168 Reference X
*2
Set/Get 0 to 99999.9999
169 Reference Y
*2
Set/Get 0 to 99999.9999
171 Line connection level Set/Get
0: 1
1: 2
2: 3
3: 4
4: 5
5: Custom
No. Data name Set/Get Data range
