Gravity and Area
330
FH/FZ5 Processing Item Function Reference Manual
*1: The reference coordinates based on the selection in the Method area of the [Ref.setting] tab can be Get only.
*2: The reference coordinates based on the selection of Numerical in the Method area of the [Ref.setting] tab can be Set/Get.
*3: N = 0 - 7 (color extraction range 0 to 7)
303 Use point coordinate before scroll Set/Get
0: Not use
1: Use
304 Position X before scroll Set/Get -99999.9999 to 99999.9999
305 Position Y before scroll Set/Get -99999.9999 to 99999.9999
311 Region reverse Set/Get
0: Not reverse
1: Reverse
312 Dilate erosion level Set/Get -10 to 10
313 Static mask type Set/Get
0: Region extract
1: Region of image reference
314 Static mask unit reference no Set/Get -1 to 9999
315 Static mask image no Set/Get 0 to 99
316 Dynamic mask unit reference no Set/Get -1 to 9999
317 Dynamic mask image no Set/Get 0 to 99
318 Mask type Set/Get
0: Static mask
1: Dynamic mask
319 Display image type Set/Get
0: Measure image
1: Mask binary image
2: Mask and image
324 Is mask Set/Get
0: OFF
1: ON
325 Mask region display color Set/Get
0: Black
1: White
2: Red
3: Green
4: Blue
6002 Format Set/Get
1: monochrome camera
2: color camera
No. Data name Set/Get Data range
