Camera Image InputFH/FZ5 Processing Item Function Reference Manual
35
1
Input image
• There is no restriction on power consumption nor on lighting mode when using lightings with lighting controller
FLV-TCC1EP. Restrictions on power consumption and lighting mode differ depending on the product series. See
the following table for details.
1. FLV-TCC4/-TCC1
• Without external power supply
• With external power supply
2. FLV-TCC3HB
• Without external power supply
0ch (spot lighting) not connected
0ch (spot lighting) connected
Important
Total power
consumption
Power consumption
per channel
Connectability
Lighting mode
*1
READY OFF
time delay
*2
Always-on
lighting mode
Simultaneous
lighting mode
Single lighting
mode
Greater than
7.5 W
Greater than 7.5 W Not connectable --- --- --- ---
7.5 W or less Connectable NA NA OK None
7.5 W or less Less than 7.5 W Connectable OK OK OK None
Total power
consumption
Power consumption
per channel
Connectability
Lighting mode
*1
READY OFF
time delay
*2
Always-on
lighting mode
Simultaneous
lighting mode
Single lighting
mode
Greater than
15 W
Greater than 15 W Not connectable --- --- --- ---
15 W or less Connectable NA NA OK Yes
7.5 W or less Connectable NA NA OK None
15 W or less
Less than 15 W Connectable NA OK OK Yes
7.5 W or less Connectable NA OK OK Yes
7.5 W or less Less than 7.5 W Connectable OK OK OK None
Total power
consumption
Power consumption
per channel
Connectability
Lighting mode
*1
READY OFF
time delay
*2
Always-on
lighting mode
Simultaneous
lighting mode
Single lighting
mode
Greater than
7.5 W
Greater than 7.5 W Not connectable --- --- --- ---
7.5 W or less Connectable NA NA OK None
7.5 W or less Less than 7.5 W Connectable OK OK OK None
Total power
consumption
Power consumption
per channel
Connectability
Lighting mode
*1
READY OFF
time delay
*2
Always-on
lighting mode
Simultaneous
lighting mode
Single lighting
mode
Greater than
5.5 W
Greater than 7.5 W Not connectable --- --- --- ---
7.5 W or less Connectable NA NA OK None
5.5 W or less Less than 5.5 W Connectable OK OK OK None
