2D CodeFH/FZ5 Processing Item Function Reference Manual
429
2
Inspecting and Measuring
RAP edge contrast GP4
A quality grade which shows the contrast of the start p
attern, stop pattern, or
specified line.
Verify the smallest contrast between bar and space.
RAP modulation GP5
A quality grade which shows the brightness uniformity of the start pattern,
stop pattern, or specified line.
Verify the lowest edge contrast as aga
inst
to the symbol contrast.
RAP defection GP6
A quality grade that shows the percen
t
age of error corrected items.
A grade which is less errors is high grade.
RAP decidability GP7
A quality grade which shows whether there is a sufficient Quiet zone for start
pattern, stop pattern, or specified line.
A grade is high when the width of bar or space is close to the standard
values
.
RAP ad
ditional GP8
A quality grade which shows whether there is a sufficient Quiet zone for start
p
a
ttern, stop pattern, or specified line.
RAP overall quality GP9
An overall quality grade for parts of the start p
attern, stop pattern, or specified
line.
Code word yield GP10
A quality grade that shows the percentage of error corrected items.
An evaluation of the number of code is succe
ssful decoded when repeat to
scan the code.
Unused error correction GP11
A quality grade that shows the percen
t
age of error corrected items.
A grade which is less errors is high grade.
Decidability GP12
A quality grade which shows the printed accuracy of codes parts.
A grade is high when the width of bar or space is close to the standard
values.
Defect GP13
A qu
ality grade which shows the uni
formity of codes brightness.
Verify the uniformity of brightness between bar and space.
Modulation GP14
A quality grade which shows the brightn
ess uniformity of the start
pattern, stop pattern, or specified line.
Verify the lowest edge contrast as against to the symbol contrast.
Measurement items Character string Description
