Advanced Filter
570
FH/FZ5 Processing Item Function Reference Manual
Setting Items for 2 Images Operation Filter
Setting item
Setting value
[Factory default]
Description
Target image 2
• Measurement
• [Pre filter image]
• Other unit image
• Filtered image
This can be set when “2 images operation
filter” is selected in “Filter
Setting”.
As target image 2, set the image that is used with the target image in the
ope
ra
tion.
The setting values that can be selected are the same as for “Target”.
Unit image 2
• [None]
•0 to 9,999
This can be set when “Filter Setting” is “2 image
s op
eration filter” and
“Processing unit image” is selected for “Target image 2”.
Set the processing unit that holds the imag
e used as
target image 2. A
processing unit of an image input processing item or image conversion
processing item can be selected. If the selected processing unit does not
hold an image, invalid image occurs and a black image is displayed.
Unit image number
2
0 to 3 [0]
This can be set when “Filter Setting” is “2 image
s op
eration filter” and
“Processing unit image” is selected for “Target image 2”.
Set the image number of the image that is
u
sed as target image 2. If the
processing unit does not hold the image of the set image number, invalid
image occurs and a black image is displayed.
Filtered image 2
• [None]
•0 to 14
This can be set when “Filter Setting” is “2 image
s operation filter” and
“Filtered image” is selected for “Target image 2”.
Set the processing unit that holds the imag
e used as
target image 2. A
processing unit that performed processing prior to the current processing
unit can be selected.
Operation type
• [Operation]
• Bit operation
Select the type of operation for 2
“Images Operation Filter”.
Operation mode
• [Add]
• Subtraction
• Subtraction
(Absol
ute)
• Multiplication
• Multiplication
(Normalization)
•Average
• Maximum
•Minimum
This setting becomes valid if “Operation” is selected for “Operation type”.
The pixel values of two images are calculated in Operation mode and the
result is
u
sed as the pixel values after conversion.
Bit operation mode
• [AND]
•OR
•XOR
•NAND
•NOR
•XNOR
This setting becomes valid if “Bit operation” is selected for “Operation
typ
e
”.
The pixel values of two images are calculated in Bit operation mode and
th
e re
sult is used as the pixel values after conversion.
The Output coordinates (Before/Afer scroll an
d
Calibration ON/OF) of the measurement unit for the image after
performing 2 images operation are calculated with the image selected in "Target"of 2 images operation.
