Camera Image Input FH
62
FH/FZ5 Processing Item Function Reference Manual
*1: Lighting modes
*2: Turning OFF the READY signal is delayed in comparison with not connecting a camera with lighting controller by
approximat
ely the exposure time.
Example: Connection example for connecting an external power supply and the lighting modes
• If four lights with a power consumption of 1 W each a
re connected to a camera with lighting controller,
always-on lighting, simultaneous lighting, and single lighting are all possible.
• If four lights with power consumptions of 2 W, 3 W, 4 W
,
and 5 W are connected to a camera with lighting
controller, simultaneous lighting and single lighting are possible.
• If four lights with power consumptions of 12 W, 1 W, 2 W
,
and 1 W are connected to a camera with lighting
controller, only single lighting is possible.
Always-on
lighting mode
In this mode, the lights are always turned ON for a specific pulse cycle. The always-on lighting mode is
used if you place a check in “On all the time” in the “Lighting control” area.
Simultaneous
lighting mode
In this mode, all of the connected lights are turned ON in synchronization with the trigger. Set the
“Adjustment” set values in the “Lighting control” area for each light to any value other than 0 for all of
the parts.
Single
lighting mode
In this mode, only one of the connected lights is turned ON in synchronization with the trigger. Set the
“Adjustment” set value in the “Lighting control” area to any value other than 0 for the part for only one
channel. The lights will not turn ON if you set two or more channels to an adjustment other than 0.
