Omron fh-3 series User Manual

Vision Master Calibration
766
FH/FZ5 Processing Item Function Reference Manual
14007+Nx10000
(N: 0 to 7)
X magnification of dataN Get only -
14008+Nx10000
(N: 0 to 7)
Y magnification of dataN Get only -
14009+Nx10000
(N: 0 to 7)
Origin X of dataN Get only -
14010+Nx10000
(N: 0 to 7)
Origin Y of dataN Get only -
14011+Nx10000
(N: 0 to 7)
X-axis angle of dataN Get only -
14012+Nx10000
(N: 0 to 7)
Y-axis angle of dataN Get only -
14013+Nx10000
(N: 0 to 7)
XY-axis angle of dataN Get only -
14016+Nx10000
(N: 0 to 7)
Error evaluation of dataN Get only -
14017+Nx10000
(N: 0 to 7)
X max error of dataN Get only -
14018+Nx10000
(N: 0 to 7)
Y max error of dataN Get only -
14019+Nx10000
(N: 0 to 7)
Sampling number of X max error of dataN Get only 0 to 204
14020+Nx10000
(N: 0 to 7)
Sampling number of Y max error of dataN Get only
0 to 204
