Vision Master CalibrationFH/FZ5 Processing Item Function Reference Manual
765
4
Support Inspection and Measurement
202+Nx10
(N: 0 to 7)
Position Y of data N Set/Get Exp. character string
203+Nx10
(N: 0 to 7)
Sampling judge expression of dataN Set/Get Exp. character string
204+Nx10
(N: 0 to 7)
Sampling judge lower of dataN Set/Get -999,999,999.9999 to 999,999,999.9999
205+Nx10
(N: 0 to 7)
Sampling judge upper of dataN Set/Get -999,999,999.9999 to 999,999,999.9999
206+Nx10
(N: 0 to 7)
Input image no. of dataN Set/Get -1 to 9,999
11301+Nx10000
(N: 0 to 7)
First calibration parameter A of dataN Get only -99999.999999 to 99999.999999
11302+Nx10000
(N: 0 to 7)
First calibration parameter B of dataN Get only -99999.999999 to 99999.999999
11303+Nx10000
(N: 0 to 7)
First calibration parameter C of dataN Get only -99999.999999 to 99999.999999
11304+Nx10000
(N: 0 to 7)
First calibration parameter D of dataN Get only -99999.999999 to 99999.999999
11305+Nx10000
(N: 0 to 7)
First calibration parameter E of dataN Get only -99999.999999 to 99999.999999
11306+Nx10000
(N: 0 to 7)
First calibration parameter F of dataN Get only -99999.999999 to 99999.999999
11307+Nx10000
(N: 0 to 7)
First X magnification of dataN Get only -
11308+Nx10000
(N: 0 to 7)
First Y magnification of dataN Get only -
11309+Nx10000
(N: 0 to 7)
First origin X of dataN Get only -
11310+Nx10000
(N: 0 to 7)
First origin Y of dataN Get only -
11311+Nx10000
(N: 0 to 7)
First X-axis angle of dataN Get only -
11312+Nx10000
(N: 0 to 7)
First Y-axis angle of dataN Get only -
11313+Nx10000
(N: 0 to 7)
First XY-axis angle of dataN Get only -
14001+Nx10000
(N: 0 to 7)
Calibration parameter A of dataN Set/Get -999,999,999.9999 to 999,999,999.9999
14002+Nx10000
(N: 0 to 7)
Calibration parameter B of dataN Set/Get -999,999,999.9999 to 999,999,999.9999
14003+Nx10000
(N: 0 to 7)
Calibration parameter C of dataN Set/Get -999,999,999.9999 to 999,999,999.9999
14004+Nx10000
(N: 0 to 7)
Calibration parameter D of dataN Set/Get -999,999,999.9999 to 999,999,999.9999
14005+Nx10000
(N: 0 to 7)
Calibration parameter E of dataN Set/Get -999,999,999.9999 to 999,999,999.9999
14006+Nx10000
(N: 0 to 7)
Calibration parameter F of dataN Set/Get
-999,999,999.9999 to 999,999,999.9999
No. Data name Set/Get Data range
