Transfer Position Data
780
FH/FZ5 Processing Item Function Reference Manual
Selects Y-axis as movement axis when
Xθ(Yθ) or θX(θY) Stage are set in
reference data.
4 Set each item in the Transferred axis position area.
Set how far each axis in the "Post-correction position/angle" moved from the origin return state (all axes
are at the origin point).
If the stage type of the reference data is
the XY stage or the robot type is 3-axis
robot
If the stage type of the reference data is
the XYθ stage, θXY stage
or the robot
type is 4-axis robot
If the stage type of the reference data is
the UVW stage
Setting item
Setting value
[Factory default]
Description
Y-axis - Set the measurement distance of Y-axis from homign operation.
θ-axis - Set the measurement distance of θ-axis from homign opera
tion.
Setting item
Setting value
[Factory default]
Description
X-axis - Set how far the X axis position moved from the origin.
Y-axis - Set how far the Y axis position moved from the origin.
Setting item
Setting value
[Factory default]
Description
X-axis - Set how far the X axis position moved from the origin.
Y-axis - Set how far the Y axis position moved from the origin.
θ-axis - Set how far the θ axis position
moved from the origin.
Setting item
Setting value
[Factory default]
Description
U-axis - Set how far the U axis position mo
ved from the origin.
V-axis - Set how far the V axis position moved from the origin.
W-axis - Set how far the W axis position moved from the origin.
