Camera Calibration
820
FH/FZ5 Processing Item Function Reference Manual
If "Length" is selected for [Dimension measure].
If "2 points" is selected for [Dimension measure].
If "Specify point" is se
lec
ted for [Origin].
3 Click [Region] as needed to set sampling measurement conditions.
4 Click [Sampling measurement].
5 Click [Generate calibration parameters].
The calibration parameters will be generated.
9 Changes display settings as needed.
Setting item
Setting value
[Factory default]
Description
Width unit No.
• Width reference unit in the
measurement flow
• [<None>]
Select the scan edge width processing unit in the
current scene.
Setting item
Setting value
[Factory default]
Description
Point 1 and 2 unit
No.
• Point width measurement unit in the
measur
ement flow
• [<None>]
Select the processing unit that can perform point
measu
r
ement in the current scene.
Setting item
Setting value
[Factory default]
Description
Camera X and Y
-99999.9999 to 99999.9999
[0]
Set the camera coordinates for a given point.
If the origin of the actual coordinates is included in
the field
of view, measure the origin position of the
actual coordinates in advance and set them to the
camera coordinates X and Y.
Changed X and Y
-99999.9999 to 99999.9999
[0]
Set the actual coordinate values set as the camera
co
or
dinates.
If the origin position of the
actual
coordinates is set
as the camera coordinates, set (0.0, 0.0).
Setting item
Setting value
[Factory default]
Explanation
Display setting
• [Input image]
• X unit image
• Y unit image
Select the type of image to display in the Image display area.
The display setting is valid only in the sampling tab screen.
