Result Display
878
FH/FZ5 Processing Item Function Reference Manual
Display cross line
When Display String, Value, Item name, Judge, Date or Display Unit string Is Selected
Sets display position, size, and color etc. of characters.
Common settings
Detail
Style
• Solid line
• Dashed line
Select the line type.
Width 1 to 10 Modify the line width.
Color
OK Color Displayed in green.
NG Color Displayed in red.
Judgement
Displayed using OK color or NG color base
d on the judgment results. Specify
measurement values subject to judgment and set up respective judgment
conditions.
Arbitrary color
Displayed using specified color. Methods for specifying color include
sp
ecifying by clickin
g on a color chart and specifying RGB values.
Setting item Setting item Description
Scale display - Place a check to show the scale.
Unit
• [Calibration]
•Pixels
Select the unit used when grids are displayed.
Interval
0.0000 to 9999.9999
[50.000
0]
Set the intervals of the scale on the grids.
Line length
0.0000 to 9999.9999
[10.000
0]
Set the length of the scale line on the grids.
Setting item Setting item Description
Display
position
Figure (or Numerical)
Select this if you would like the figure to always display in the same location.
Methods include specifying by clicking on the window and specifying
co
ordinate values.
However, if you would like to always displa
y the fi
gure in a reference position,
set an expression using "Operation".
Operation
Select this when you would like to change display position for each
measuremen
t based on the measured value. Set up the expression to
specify the display position.
Setting item Setting item Description
Align
•Top
• Bottom
•Left
•Center
• Right
Specify the alignmen
t of th
e text.
Size 10 to 200 Specify the font size.
Angle 0 to 359 Specify the display angle.
Setting item Setting item Description
