Result DisplayFH/FZ5 Processing Item Function Reference Manual
879
7
Display result
Display string
Display judge
Display date
Display value
Display item name
Style
•Bold
• Italic
• Under line
• Mark out
Specify the character decoration.
Color
OK Color Displayed in green.
NG Color Displayed in red.
Judgement
Displayed using OK color or NG color based on the judgment results. Specify
measuremen
t values subject to judgment and set up respective judgment
conditions.
Arbitrary color
Displayed using specified color. Methods for specifying color include
sp
ecifying by clicking on a color chart and specifying RGB values.
Setting item Description
Set letter Set characters within 64 characters.
Setting item Description
Judge type
Specify measurement values subject to judgment and set up respective judg
ment conditions. Displays using
OK letter or NG letter based on the judgment results.
Judgement
co
ndi
tion
OK letter Sets characters displayed for the case that judgment results are OK.
NG letter Sets characters displayed for the case that judgment results are NG.
Setting item Setting item Description
Date kind
• Month/Day/Hour/Minute/
Second
• Month/Day/Hour/Minute
• Hour/Minute/Second
• Hour/Minute
Select display format
Please adjust the calendar time that comes with the controller in advance.
Reference: "Chapter 6 Changing the System Environment Setting the
Syste
m
Operation Environment Setting the Date and Time [Date-time
Setting]" in the "Vision System FH/FZ5 Series User's Manual (Z365)"
Setting item Setting item Description
Measurement - Specify the measurement value you would like to display using expression.
Digits of
integer
1 to 10
Specify the digits of the integer part including the sign. Fo
r positive numbers, the plus sign is
not output.
Example
Setting: 4 digits, data -5619
-999 is output.
Decimal 0 to 4
Set the number of decimal fraction digits. Decimals are rounded up and output. When 0 is
sele
cted, the decimal digits will be rounded off.
Setting item Description
Processing item Choose processing item name from among the scenes being displayed.
Setting item Setting item Description
