Advanced FilterFH/FZ5 Processing Item Function Reference Manual
581
3
Compensate image
Sort condition
• Area ascending
• [Area descending]
• X ascending
• X descending
• Y ascending
• Y descending
• Elliptic major axis ascending
• Elliptic major axis descending
• Elliptic minor axis ascending
• Elliptic minor axis descending
• Elliptic ratio ascending
• Elliptic ratio descending
• Rectangle width ascending
• Rectangle width descending
• Rectangle height ascending
• Rectangle height descending
• Rectangle X1 ascending
• Rectangle X1 descending
• Rectangle Y1 ascending
• Rectangle Y1 descending
• Perimeter ascending
• Perimeter descending
• Circularity ascending
• Circularity descending
• Fit rect major axis ascending
• Fit rect major axis descending
• Fit rect minor axis ascending
• Fit rect minor axis descending
• Fit rect ratio ascending
• Fit rect ratio descending
• Inscribed circle X ascending
• Inscribed circle X descending
• Inscribed circle Y ascending
• Inscribed circle Y descending
• Inscribed circle R ascending
• Inscribed circle R descending
• Circum. circle X ascending
• Circum. circle X descending
• Circum. circle Y ascending
• Circum. circle Y descending
• Circum. circle R ascending
• Circum. circle R descending
• Number of holes ascending
• Number of holes descending
This can be set when the [Specify label No.] checkbox is selected.
In order to specify a label, set the condition for sorting labels.
Label No. 0 to 2,499 [0]
This can be set when the [Specify label No.] checkbox is selected.
Set the number of the label to be specified.
Setting item
Setting value
[Factory default]
Description
