Advanced Filter
582
FH/FZ5 Processing Item Function Reference Manual
Extraction condition
• [None]
•Area
•X
•Y
• Elliptic major axis
• Elliptic minor axis
• Elliptic ratio
• Rectangle width
• Rectangle height
• Rectangle X1
• Rectangle Y1
• Perimeter
• Circularity
• Fit rect major axis
• Fit rect minor axis
• Inscribed circle R
• Circum. circle R
• Number of holes
Set the conditions for extracting a label.
Up to three extraction conditions can be set.
Extraction condition
upp
er/l
ower limit
[-999,999,999.9999] to
[999,999,999.9999]
Set the upper limit and lower limit of the condition for extracting a label.
Extraction condition
setting
•[AND]
•OR
Set the condition for combining extraction conditions.
•AND
Labels meeting all extraction conditions are extracted.
•OR
Labels meeting any one of the extracti
on cond
itions are extracted.
Output image
• [Binary image]
• All color image
Appears when the settings are for a color image.
Set the image that is output as the image filtered by the labeling filter.
Setting item
Setting value
[Factory default]
Description
To Next Page
