Advanced FilterFH/FZ5 Processing Item Function Reference Manual
591
3
Compensate image
S [0] to [255] Set the saturation (difference in saturation).
V [0] to [255] Set the vividness (difference in
vividness).
Exclude this color
•Checked
• [Unchecked]
To exclude a selected color extraction range from the extracted colors, select
“Exclude this c
o
lor”.
Background color
• [Black]
•White
•Red
•Green
•Blue
Set the color used to cover background color parts other than the color to be
ext
racted.
When “Color selected image” is selected
in
“Display”, the background color
can be set for each selected color. When “All color image” is selected in
“Display”, background color parts are covered with the background color of
Color 0.
Fill profile
•[OFF]
• Fill profile
• Filling up holes
Set the fill method for filling a central blank part of an image.
•OFF
Do not fill central blank part.
• Fill profile
As the extracted color, measure the interval
betwee
n the extract color start
point and extract color end point in the direction of the X axis in the
measurement region. Filling only takes place in the direction of the X axis,
and thus this method is faster than “Filling up holes”.
• Filling up holes
Fill the blank “donut hole” surrounded by th
e extra
cted color with the
extracted color
Output image
• [Binary image]
• All color image
Set the image that is output after filterin
g b
y the Extract Color filter.
Display
• Measurement
• [All color image]
• Selected color
• Binary image
Set the image that you want to display in the settings screen.
Setting item
Setting value
[Factory default]
Description
