Advanced Filter
598
FH/FZ5 Processing Item Function Reference Manual
4 Set the model image target file.
Select the check box for the files to register as the model from the model image list.
Up to 100 image files can be registered as the model.
Setting item
Setting value
[Factory default]
Description
No. of images ---
Displays the number of images to be used as a model.
• Previous
Displays the number of images when a model was registered last.
• Current
Displays the number of images to be registered as a model of which
ch
eck b
ox is selected in the model image list.
Model image list ---
This is a list of image files stored in the folder specified in [Folder name].
Check boxes, flags, and file names are displayed.
Files with selected check boxes are targe
t
files to be registered as a
model.
A check indicates the model registration st
atus
when the image files were
registered last.
Image files with a selected check box wh
en [R
egister model] is clicked
are updated.
• Check
Error: Image files that were used in the la
st registration but currently not
found.
Disabled: Image files existing in the mod
e
l registration list but not used to
generate a model image.
Not set: Image files that did not exist in the last model registration.
Enabled: Image files registered last time.
• In the model image list, BMP image files are displayed.
• [Delete all] deletes all files in [Folder name]. F
i
les other than images files are deleted as well.
• [Delete one] deletes the image file selected in the model image list.
• Files with [Error] will be deleted from the li
st whe
n [Register model] is clicked.
Important
