Stage DataFH/FZ5 Processing Item Function Reference Manual
725
4
Support Inspection and Measurement
16 Likewise, click [...] in [VY] in the Setting by XY coordinate system area to set a value for the V
axis pivot point's Y coordinate in the return to origin status.
17 Likewise, click [...] in [WX] in the Setting by XY coordinate system area to set a value for the W
axis pivot point's X coordinate in the return to origin status.
18 Likewise, click [...] in [WY] in the Setting by XY coordinate system area to set a value for the W
axis pivot point's Y coordinate in the return to origin status.
19 Likewise, click [...] in [RX] in the Setting by XY coordinate system area to set a value for the R
axis pivot point's X coordinate in the return to origin status.
20 Likewise, click [...] in [RY] in the Setting by XY coordinate system area to set a value for the R
axis pivot point's Y coordinate in the return to origin status.
21 Likewise, click [...] in [Rotation center X] in the Setting by XY coordinate system area to set a
value for the rotation center's X coordinate in the return to origin status.
22 Likewise, click [...] in [Rotation center Y] in the Setting by XY coordinate system area to set a
value for the rotation center's Y coordinate in the return to origin status.
23 The Setting by Polar coordinate system area is enabled if [Setting by Polar coordinate
system] is selected in [Axis parameter setting].
24 Click [...] in [R1] in the Setting by Polar coordinate system area to set the distance between
the U axis pivot point and rotation center in the return to origin status.
25 Likewise, click [...] in [R2] in the Setting by Polar coordinate system area to set the distance
between the V axis pivot point and rotation center in the return to origin status.
26 Likewise, click [...] in [R3] in the Setting by Polar coordinate system area to set the distance
between the W axis pivot point and rotation center in the return to origin status.
27 Likewise, click [...] in [R4] in the Setting by Polar coordinate system area to set the distance
between the R axis pivot point and rotation center in the return to origin status.
28 Likewise, click [...] in [θ1] in the Setting by Polar coordinate system area to set a value.
29 Likewise, click [...] in [θ2] in the Setting by Polar coordinate system area to set a value.
30 Likewise, click [...] in [θ3] in the Setting by Polar coordinate system area to set a value.
31 Likewise, click [...] in [θ4] in the Setting by Polar coordinate system area to set a value.
To Next Page
