Calc Axis MoveFH/FZ5 Processing Item Function Reference Manual
789
4
Support Inspection and Measurement
: Show, : Hide
Initial angle
Initial angle is an angle when the offset amount is calculated.
Example) Positioning of a ceramic chip by using the angle of the diagonal line and the center
position.
Definition of symbol in the following figure
• Measurement position/angle of when the offset amount is calculated (MX, MY, MT)
• Reference position/angle when the offset amount is calculated (SX, SY, ST)
• Offset amount of measurement posi
t
ion/angle (OMX, OMY, OMT)
• Offset amount of the reference position/angle (OSX, OSY, OST)
Setting contents for "Measurement position offset setting" of the Calc Axis Move
• Position X : OMX = SX - MX
• Position Y : OMY = SY - MY
• Angle : OMT = ST - MT
• Angle at the definition time : MT
Current axis
po
si
tion
X-axis      

(X-axis is
selected as the
Movement
axis)

(X-axis is
selected as the
Movement
axis)

(X-axis is
selected as the
Movement
axis)
 
Y-axis      

(Y-axis is
selected as the
Movement
axis)

(Y-axis is
selected as the
Movement
axis)

(Y-axis is
selected as the
Movement
axis)
 
θ-axis           
U-axis           
V-axis           
W-axis           
R-axis          

Displayed
content
Not
selec
ted
XY XYθ θXY UVW UVWR X(Y) Xθ(Yθ) θX(θY)
3
axes
4
axes
