Advanced FilterFH/FZ5 Processing Item Function Reference Manual
567
3
Compensate image
3 Click [OK].
The filter is added to the end of list in the filter setting list area.
When [Insert] is clicked to add the filter, the filter
is added to the selected position in the list.
4 Select the filter in the list in the filter setting list area.
5 Click [Edit].
The filter edit screen appears.
Reference: Changing the Filter Settings (p.568)
Brightness Correct Filter
Filter for monochrome images.
Same function as the brightness correct filter in the “Filtering” processing item.
Corrects the effects of lighting as well as properties of the ob
ject of measurement such as
material and shape.
Reference: Changing the Brightness Correct Filter Settings (Monochrome Images Only)
(p.575)
Stripes Removal Filter II
Filter for monochrome images.
Same function as the stripes removal filter in the “S
trip
es Removal Filter II” processing
item.
Removes a striped background.
Reference: Changing the Stripes Removal Filter II Settings
(Monochrome Images Only)
(p.576)
Labeling Filter
Filter that binarizes the image based on the same extraction conditions as the Labeling
processing item.
Reference: Changing the Labeling Filter Settings (p.577)
Custom Linear Filter
Linear filter that allows you to set cus
tom filter coefficients.
You can set a filter count, mask size, offset,
and other parameters for filtering.
Reference: Changing the Custom Linear Filter Settings (p.583)
Custom Rank Filter
Rank filter that allows you to set custom filter coef
ficients.
You can set a filter count, mask size, processing method, and other parameters for filtering.
Reference: Changing the Custom Rank Fi
lter Se
ttings (p.584)
Image operation
Filter that converts the image b
y
calculating pixel values.
Reference: Changing the Image Operation Filter Settings (p.585)
2 images operation
Filter that converts the image by calculatin
g the paired pixel values of two images.
Reference: Changing the 2 Images Operation Settings (p.587)
Binary
Filter for monochrome images.
Binarizes the image.
Reference: Changing the Binary Filter Settings (Monochrome Images Only) (p.588)
Color gray filter
Filter for color images.
Same function as Color Gray filter in the “Color
Gray filter” processing item.
Converts color images to monochrome.
Reference: Changing the Color Gray Filter Settings (Color Images Only) (p.589)
Extract Color Filter
Filter for color images.
Same function as the extract color filter in the
“Extract
Color Filter” processing item.
Extracts color from color images.
Reference: Changing the Extract Color Filter Settings (Color Images Only) (p.590)
Anti Color Shading
Filter for color images.
Same function as the Anti Color Shading filter in the “Anti Color Shading” processing item.
Removes uneven color in the image.
Reference: Changing the Anti Color Shading Filter Settings (Color Images Only) (p.592)
Image subtraction filter
Image subtraction filter is similar to "subtract
o
nly" of the "Image subtraction" processing
item.
It extracts the difference between the model image and measured image.
Reference: Changing the Settings for Image Subtraction Filter (p.593)
Setting item Description
To Next Page
