H3C S7500E Series Command Manual

Command Manual – IP Addressing and Performance
H3C S7500E Series Ethernet Switches
Chapter 2 IP Performance Configuration
Commands
2-2
Flag:
U:Useable G:Gateway H:Host B:Blackhole D:Dynamic S:Static
R:Reject L:Generated by ARP or ESIS
Destination/Mask Nexthop Flag TimeStamp Interface Token
10.2.0.0/16 0.0.0.0 U t[1150900568] Vlan1 invalid
10.2.1.1/32 127.0.0.1 HU t[1150900568] InLoop0 invalid
127.0.0.0/8 127.0.0.1 U t[1150623094] InLoop0 invalid
127.0.0.1/32 127.0.0.1 HU t[1150623094] InLoop0 invalid
Table 2-1 Description on the fields of the display fib command
Field Description
Total number of Routes Total number of routes in the FIB table
Destination/Mask Destination address/length of mask
Nexthop Address of next hop
Flag
Flags of routes:
z “U”—Usable route
z “G”—Gateway route
z “H”—Host route
z “B”—Blackhole route
z “D”—Dynamic route
z “S”—Static route
z “R”—Refused route
z “L”—Route generated by ARP or ESIS
TimeStamp Time stamp
Interface Forward interface
Token LSP index number
# Display FIB information passing ACL 2000
<Sysname> system-view
[Sysname] acl number 2000
[Sysname-acl-basic-2000] rule permit source 10.2.0.0 0.0.255.255
[Sysname-acl-basic-2000] display fib acl 2000
Route entry matched by access-list 2000:
Summary counts: 2
Flag:
U:Useable G:Gateway H:Host B:Blackhole D:Dynamic S:Static
R:Reject L:Generated by ARP or ESIS
Destination/Mask Nexthop Flag TimeStamp Interface Token
