H3C S7500E Series Command Manual

Command Manual – RRPP
H3C S7500E Series Ethernet Switches Chapter 1 RRPP Configuration Commands
1-3
Table 1-1 Description on the fields of the display rrpp brief command
Field Description
Flags for Node Mode
RRPP node mode: M represents master node, T
represents transit node, E represents edge node
and A represents assistant edge node
RRPP Protocol Status
RRPP protocol status: Enable (globally
enabled)/Disable (globally disabled)
Number of RRPP Domains Number of RRPP domains configured
Domain ID RRPP domain ID
Control VLAN
Control VLANs of an RRPP domain: Major and
Sub
Hello Timer Hello Timer value configured in seconds
Fail Timer Fail Timer value configured in seconds
Ring ID RRPP ring ID
Ring Level
RRPP ring level, with 0 representing primary ring
and 1 representing subring
Node Mode Node mode
Primary/Common Port
Primary port when the node mode is master node
or transit node; common port when the node mode
is edge node or assistant edge node; “-“ appears
when the port is not configured on the ring or the
board to which the port belongs does not start.
Secondary/Edge Port
Secondary port when the node mode is master
node or transit node; edge port when the node
mode is edge node or assistant edge node;
“-“ appears when the port is not configured on the
ring or the board to which the port belongs does
not start.
Enable Status
RRPP ring status: Yes indicates enabled and No
indicates disabled.
1.1.3 display rrpp statistics
Syntax
display rrpp statistics domain domain-id [ ring ring-id ]
View
Any view
Parameters
domain-id: RRPP domain ID, in the range 1 to 8.
