H3C S7500E Series Ethernet Switches Chapter 1 RRPP Configuration Commands
1-6
Field Description
Secondary Port
The secondary port field means the node mode is master
node or transit node. “-” appears when the port is not
configured on the ring, and in this case, no corresponding
statistics appears.
Common Port
The common port field means the node mode is edge node
or assistant edge node. “-” appears when the port is not
configured on the ring, and in this case, no corresponding
statistics appears.
Edge Port
The edge port field means the node mode is edge node or
assistant edge node. “-” appears when the port is not
configured on the ring, and in this case, no corresponding
statistics appears.
Packet Direct Packet transmission direction on the port: Send or Rcv
Health Health packet statistics received/sent on the port
Link-Down Link-Down packet statistics received/sent on the port
Common Flush FDB
Common-Flush-FDB packet statistics received/sent on the
port
Complete Flush
FDB
Complete-Flush-FDB packet statistics received/sent on the
port
Packet Total
Total number of packets received/sent on the port. Here only
Health, Link-Down, Common-Flush-FDB and
Complete-Flush-FDB packets of RRPP are taken statistics.
1.1.4 display rrpp verbose
Syntax
display rrpp verbose domain domain-id [ ring ring-id ]
View
Any view
Parameters
domain-id: RRPP domain ID, in the range 1 to 8.
ring-id: RRPP ring ID, in the range 1 to 64.
Description
Use the display rrpp verbose command to display detailed information about RRPP
configuraiton.
