H3C S7500E Series Command Manual

Command Manual – RRPP
H3C S7500E Series Ethernet Switches Chapter 1 RRPP Configuration Commands
1-5
Packet Link Common Complete Packet
Direct Health Down Flush FDB Flush FDB Total
------------------------------------------------------------------------
Send 16924 0 0 1 16925
Rcv 0 0 0 0 0
Secondary port: GigabitEthernet3/0/4
Packet Link Common Complete Packet
Direct Health Down Flush FDB Flush FDB Total
------------------------------------------------------------------------
Send 0 0 0 0 0
Rcv 16878 0 0 1 16879
Ring ID : 2
Ring Level : 1
Node Mode : Edge
Active Status : No
Common port : GigabitEthernet3/0/3
Packet Link Common Complete Packet
Direct Health Down Flush FDB Flush FDB Total
------------------------------------------------------------------------
Send 0 0 0 0 0
Rcv 0 0 0 0 0
Edge port : GigabitEthernet3/0/5
Packet Link Common Complete Packet
Direct Health Down Flush FDB Flush FDB Total
------------------------------------------------------------------------
Send 0 0 0 0 0
Rcv 0 0 0 0 0
Table 1-2 Description on the fields of the display rrpp statistics command
Field Description
Ring ID RRPP ring ID
Ring Level RRPP ring level: 0 for primary ring and 1 for subring
Node Mode
Node mode: master node, transit node, edge node and
assistant edge node
Active Status
RRPP ring activation status: Yes indicates active and No
indicates inactive (An RRPP is active only if the RRPP ring is
enabled and the RRPP protocol is globally enabled)
Primary Port
The primary port field means the node mode is master node
or transit node. “-“ appears when the port is not configured
on the ring, and in this case, no corresponding statistics
appears.
