H3C S7500E Series Ethernet Switches Chapter 1 PoE Configuration Commands
1-7
Eth2/0/39 disable low 0.0 off 0 disabled
Eth2/0/40 disable low 0.0 off 0 disabled
Eth2/0/41 disable low 0.0 off 0 disabled
Eth2/0/42 disable low 0.0 off 0 disabled
Eth2/0/43 disable low 0.0 off 0 disabled
Eth2/0/44 disable low 0.0 off 0 disabled
Eth2/0/45 disable low 0.0 off 0 disabled
Eth2/0/46 disable low 0.0 off 0 disabled
Eth2/0/47 disable low 0.0 off 0 disabled
Eth2/0/48 disable low 0.0 off 0 disabled
--- 2 port(s) on, 9.2 (W) consumed, 90.8 (W) remaining ---
Table 1-3 Description on the fields of the display poe interface command
Field Description
Interface Shortened form of a PoE interface
Enable
PoE state: enabled/disabled
z enable: PoE is enabled.
z disable: PoE is disabled.
Priority
Power priority of a PoE interface:
z critical (highest)
z high
z low
CurPower Current power of a PoE interface
Operating Status
Operating state of a PoE interface
z off: PoE is disabled.
z on: Power is supplied for a PoE interface normally.
z power lack: The guaranteed remaining power of the PSE is
not high enough to supply power for a critical PoE interface.
z power-deny: The PSE refuses to supply power. The power
required by the powered device (PD) is higher than the
configured power.
z power-itself: The external equipment is supplying power for
itself.
power-limit: The PSE is supplying a limited power. The power
required by the PD is higher than the configured power and the
PSE still supplies the configured power.
IEEE class PD power class defined by IEEE
