Command Manual – MSTP
H3C S7500E Series Ethernet Switches Chapter 1 MSTP Configuration Commands
1-11
<Sysname> display stp instance 0 tc slot 1
-------------- STP slot 1 TC or TCN count -------------
MSTID Port Receive Send
0 GigabitEthernet2/0/1 6 4
0 GigabitEthernet2/0/2 0 2
Table 1-8 Description on the fields of the display stp tc command
Field Description
MSTID MSTP instance ID in the MST region
Port Port name
Receive Number of TC BPDUs received on each port
Send Number of TC BPDUs received by each port
1.1.10 instance
Syntax
instance instance-id vlan vlan-list
undo instance instance-id [ vlan vlan-list ]
View
MST region view
Parameters
instance-id: spanning tree instance ID, ranging from 0 to 31, with 0 representing the
CIST.
vlan vlan-list: Defines one or multiple VLANs. You can provide up to 10 VLAN lists, by
each of which you can specify an individual VLAN in the form of vlan-id, or a VLAN
range in the form of start-vlan-id to end-vlan-id, where the end VLAN ID must be
greater than the start VLAN ID. The effective range of a VLAN ID is 1 to 4094.
Description
Use the instance command to map the specified VLAN(s) to the specified spanning
tree instance.
Use the undo instance command to remap the specified VLAN(s) or all VLANs to the
CIST (spanning tree instance 0).
By default, all VLANs are mapped to the CIST.
Notice that:
