H3C S7500E Series Ethernet Switches Chapter 4 PIM Configuration Commands
4-25
<Sysname> display pim routing-table
Total 0 (*, G) entry; 1 (S, G) entry
(172.168.0.12, 227.0.0.1)
RP: 2.2.2.2
Protocol: pim-sm, Flag: SPT LOC ACT
UpTime: 02:54:43
Upstream interface: Vlan-interface1
Upstream neighbor: NULL
RPF prime neighbor: NULL
Downstream interface(s) information:
Total number of downstreams: 1
1: Vlan-interface2
Protocol: pim-sm, UpTime: 02:54:43, Expires: 00:02:47
Table 4-9 Description on the fields of the display pim routing-table command
Field Description
Total 0 (*, G) entry; 1 (S, G) entry
Number of (S, G) and (*, G) entries in the PIM
routing table
(172.168.0.2, 227.0.0.1) An (S, G) entry in the PIM routing table
Protocol PIM mode, PIM-SM or PIM-DM
Flag
Flag bit of the (S, G) or (*, G) entry in the PIM
routing table
Uptime
Length of time for which the (S, G) or (*, G) entry
has been existing
Upstream interface
Upstream (incoming) interface of the (S, G) or (*,
G) entry
Upstream neighbor Upstream neighbor of the (S, G) or (*, G) entry
RPF prime neighbor
RPF neighbor of the (S, G) or (*, G) entry
z For a (*, G) entry, if this router is the RP, the
RPF neighbor of this (*, G) entry is NULL.
z For a (S, G) entry, if this router directly
connects to the multicast source, the RPF
neighbor of this (S, G) entry is NULL.
Downstream interface(s)
information
Information of the downstream interface(s),
including:
z Number of downstream interfaces
z Downstream interface name
z PIM mode on the downstream interface(s)
z Uptime of the downstream interface(s)
z Expiry time of the downstream interface(s)
