Command Manual – VLAN
H3C S7500E Series Ethernet Switches Chapter 1 VLAN Configuration Commands
1-19
inbound packets, in the range 0x0600 to 0xffff (excluding ipx snap under the snap
encapsulation format).
protocol-index: Beginning protocol index, in the range 0 to 15. The system will
automatically assign an index if this parameter is not specified.
to protocol-end: Specifies the end protocol index, which ranges from 0 to 15 and must
be greater than or equal to the protocol-index argument.
all: Specifies all the protocol indexes.
Caution:
z Ensure that the dsap-id and ssap-id arguments are not configured as 0xe0 that
corresponds with ipx llc at the same time, or as 0xff that corresponds with ipx raw
at the same time. When either of the dsap-id and ssap-id arguments is configured,
the system assigns aa to the other argument.
z Ensure that the etype keyword is not configured as 0x0800, 0x8137, 0x809b, or
0x86dd, as which are identical to protocol templates of IPv4, IPX, AppleTalk, and
IPv6 respectively.
Description
Use the protocol-vlan command to configure the VLAN as a protocol based VLAN and
the protocol template.
Use the undo protocol-vlan command to remove the configured protocol template.
Related commands: display protocol-vlan vlan.
 Note:
To make sure that data can be transmitted properly, do not configure a VLAN as a
protocol-based VLAN and voice VLAN at the same time.
Examples
# Specify VLAN 3 as the IPv4 based VLAN to make the VLAN transmit IPv4 packets.
<Sysname> system-view
[Sysname] vlan 3
[Sysname-vlan3] protocol-vlan ipv4
