LE910Cx AT Commands Reference Guide
80502ST10950A Rev. 14 Page 1068 of 1904 2022-03-04
Not Subject to NDA
3.13.4. AT#MSDPUSH - IVS Push Mode Activation
This command allows to enable IVS to issue the request for MSD transmission.
SIM Presence
Setting saved
Can be aborted
MAX timeout
SELINT
Not required
No
No
-
2
AT#MSDPUSH
Execution command enables IVS to issue the request for MSD
transmission.
The downlink signal format is reused to send an initiation message to
the PSAP.
AT#MSDPUSH=?
Test command returns OK result code.
